ProLED Essential Round Highbay 240W 5000K Univeral Voltage 120-277VAC 0-10V Dimming Black

Essential Round Highbay

Where to Buy

Direct Sub 37313

Product ID: 37303

Product Code: ERHB-240-50-U

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Multiple Mounting Options (sold Separately)
Easy Plug and Play Motion Sensor Accessory
DLC 5.1 Premium
"Driver on Top" for greater Heat Dissipation
6kv Driver Surge Protection

View Spec Sheet

Where to Buy

Direct Sub 37313

Product Description

The Essential Round Highbay offers the perfect balance of affordability and performance for a wide array of application including warehouses, gymnasiums,big box stores, and showrooms. In addition to its excellent lumen efficacy and longevity, its powder coated die-cast aluminum housing and polycarbonate lens, along with its IP65 Wet Location rating delivers a robust and high preforming luminaire. Finally, the Essential Round Highbay offers excellent versatility and ease of installation through its included 6ft cord and 1/2in NPT steel hook. Optional yoke and pendant mounts (sold Separately).

Specifications

Product Detail

Manufacturer Halco Lighting Technologies
Color Temp 5000K
UPC 807154373031
Brand Halco
Technology LED
Size 12.6in
Shape Round
Watts 240W
Equivalent Watts 400W MH
Dimmable Yes (0-10V)
Wattage Selectable No
Color Selectable No
Amps 120VAC (1.67A) 277VAC (0.87A)
Included Accessory Included 6ft cord and 1/2in NPT steel hook
Applications warehouses gymnasiums big box stores and showrooms
Voltage 120-277V
Market Commercial, Industrial

Performance

Lumens 33000
Average Life 50,000
Color Rendering Index (CRI) 80
Beam Angle 90
Warranty (years) 5
Min Operating Temp -30C (-22F)
Max Operating Temp 50C (122F)

Packaging, Weights & Dimensions

Sold in Multiples of 1
Master Carton Size 4
Weight per Item 5.3
Inner Package Size 1

Construction

Mount Included Yes 1/2in NPT steel hook (yoke and pendant mounts option sold separately)
Finish Black Powder Coated
Lens Polycarbonate Lens
With Lens Guard Wire Guard Accessory sold separately
Housing Material Die-cast Aluminum with Powder Coated Finish
