xEvade LED Exit Sign & Emergency Unit Combo Red Lettering White Thermoplastic Universal Single / Double Face Suitable for Wall, Ceiling and End Mount
Exit Sign & Emergency Unit Combo
Direct Sub
97102
Product ID: 95005
Product Code: EV-EXC-RD
- Rugged, injection-molded, flame retardant, high-temperature, white thermoplastic housing
- Universal Single / Double Face
- 120 / 277 VAC Input
- LED life-cycle exceeding 10 years
- Maintenance free NiCad battey
- UL 924 Damp Location Listed
- 10°C - 40°C Operating temperature
- Emergency Test Button and Battery Charging Indicator
Sign In To See Price
Direct Sub
97102
Product Description
The Evade Exit and Emergency Unit Combo Series offers a quality exit and emergency lighting solution for hallway, stairwell, and other Life Safety applications. The low profile design makes it ideal to mount on walls or ceilings indicating and illuminating the path of egress for a minimum of 90 minutes after a power loss.
Product Detail
- Manufacturer Halco Lighting Technologies
- Color Temp 5700K
- UPC 807154950058
- Brand Halco
- Technology LED
- Watts 2.8W
- Dimmable No
- Wattage Selectable No
- Color Selectable No
- Input Frequency 60Hz
- Applications Life Safety
- Voltage 120-277VAC
- Market Commercial, Industrial
Performance
- Lumens 150
- Average Life 10 Year LED
- Warranty (years) 2 Year Battery
- Power Factor 0.9
- Min Operating Temp 10C (50F)
- Max Operating Temp 40C (104F)
Packaging, Weights & Dimensions
- Sold in Multiples of 1
- Master Carton Size 6
- Weight per Item 3.2
- Product Length 16.8"
- Product Width 1.8"
- Product Height 7.25"
- Box Length 14.8"
- Box Width 2.3"
- Box Height 7.5"
- Inner Package Size 1
Construction
- Mount Included Universal J-Box Mounting Pattern on Back Plate
- Mount Options Suitable for Wall and Ceiling Mount
- Finish White
- Housing Material Injection-Molded Thermoplastic Housing
Certifications
- ETL Listed No
- DLC Qualified No
- Energy Star Certified No
- Environment (wet, damp,etc) Damp
- UL Listed Yes
- Title 20 Yes
- Title 24 No
- RoHs No
- Certifications UL 924 Listed - Title 20 - Damp Location Rated
Halco-Exit-Emergency-Combination-Series-Evade-EV-EXC.pdf
EV-EXC-RD_95005_Exit-Emergency-Combo.ies
