Evade Emergency LED Light Unit Black Thermoplastic 2 Round Heads Battery Backup T20
Emergency Light
Product ID: 96008
Product Code: EV-EME-R-BK
- Rugged, injection-molded, flame retardant, high-temperature white thermoplastic housing
- Suitable for ceiling or wall mount
- 120 / 277V AC Input
- Long life, LED fully adjustable lamp head
- UL 924 Damp Location Listed
- 10C - 40C Operating temperature
- Maintenance free NiCad battery- 90Min of power
- Emergency Test Button and Battery Charging Indicator
Sign In To See Price
Product Description
The Evade Emergency Unit Series offers a quality emergency lighting solution along the path of egress for hallway, stairwells, and other Life Safety applications. The compact design makes it ideal to mount on walls or ceilings, illuminating the path of egress for a minimum of 90 minutes after a power loss
Product Detail
- Manufacturer Halco Lighting Technologies
- UPC 807154960088
- Brand Halco
- Technology LED
- Watts 1W
- Dimmable No
- Wattage Selectable No
- Color Selectable No
- Applications Commercial Buildings, Offices, Schools, Hospitals, Retail, etc and Industrial Warehouses, Distribution Centers for Life Safety
- Voltage 120-277V
- Market Commercial, Industrial
Performance
- Lumens 240
- Average Life 50,000
- Warranty (years) 2
- Min Operating Temp 10C (50F)
- Max Operating Temp 40C (104F)
Packaging, Weights & Dimensions
- Sold in Multiples of 1
- Master Carton Size 12
- Weight per Item 1.1
- Product Length 4.72in
- Product Width 2.56in
- Product Height 9.06in
- Box Length 14.58in
- Box Width 9.46in
- Box Height 10.84in
- Inner Package Size 1
Construction
- Mount Included Universal J-Box Mounting Pattern on Back Plate
- Mount Options Universal J-box mounting pattern on back plate
- Finish Black
- Lens Acrylic
- Housing Material Injection-Molded Thermoplastic
Controls
- Emergency Backup Available Yes
Certifications
- ETL Listed No
- DLC Qualified No
- Energy Star Certified No
- Environment (wet, damp,etc) Damp
- IP Rating No
- IC Rated No
- UL Listed Yes
- Title 20 Yes
- Title 24 No
- JA-8 No
- RoHs No
- Certifications UL 924 Damp Location Listed - NFPA 101 - NFPA 70 - CEC T20
Halco-Emergency-Light-Evade-Series-EV-EME-SpecSheet.pdf
EV-EME-R_96008_Evade-Emergency-2-head-unit.ies
